Specialized Turbo Levo 4 Comp Alloy

Turbo Levo 4, Where Super Meets Natural

SuperNatural Power, Ride, and Range

The Specialized Science Club Introduces the Levo 4, an electric mountain bike so advanced it transforms you into a cycling cyborg. Together you're SuperNatural, fortified with super power, traction, control, and range to conquer any off-road terrain. Levo 4, Where Super Meets Natural.

At a Glance

Use:  Full Power E-MTB Trail

E-System:  Specialized 3.1 Motor w/ 666 Watts & 101Nm, 840Wh Battery, up to 5.33 hour range

Frame:  Premium M5 Alloy, Geo Adj & SWAT Storage

Suspension:  Front: 160mm FOX FLOAT 36 Rhythm GRIP<br>Rear: 150mm GENIE - FOX FLOAT X Performance

Drivetrain:  SRAM 90 Eagle T-Type Mechanical

Wheels:  Specialized Alloy Rims / Bear Pawls hubs

Specifications

E-bike
UI/RemoteAll New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized App
Motor:  All New Specialized 3.1 Motor, 101Nm torque, 666Nm power
Charger:  Specialized 4amp charger
Battery:  840Wh battery

Frameset
Seat Binder:  Alloy, 38.6mm
Frame:  All new Levo 4 M5 Alloy frame, 150mm travel,, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29" front wheel/27.5" rear wheel, fork travel up to 180mm

Suspension
Rear Shock:  FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment
Fork:  FOX 36 Rhythm, 29", S2-S6: 160mm S1: 150mm, GRIP damper with Sweep adjust, 44mm offset, 15x110mm boost, through axle

Brakes
Front Brake:  SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Centerline rotor
Rear Brake:  SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor

Drivetrain
Cassette:  SRAM XS-1275, 12-speed, 10-52t:
Chainrings:  SRAM 34t T-Type chainring, 104 BCD, steel:
Chain:  SRAM GX Eagle T-Type Flattop Chain, 12-speed
Shift Levers:  SRAM 90 trigger, 12-speed, single click
Rear Derailleur:  SRAM Eagle 90 T-Type
Crankset:  SRAM S1000 Crankset, ISIS Interface, Integrated Guard, 55mm Chainline, 155mm

Wheels & tyres

Front Hub:  Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Tyre:  Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 27.5x2.4"
Front Tyre:  Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 29x2.4"
Spokes:  DT Swiss Industry
Rear Hub:  Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Rims:  Specialized, hookless alloy, 30mm inner width, tubeless ready
Inner Tubes:  Standard, Presta valve

Cockpit
Stem:  Alloy Trail Stem, 35mm bar bore
Handlebars:  Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm width, S3-S6 800mm width
Saddle:  Bridge Comp, Hollow Cr-mo rails, 155/143mm
Grips:  Specialized Trail Grips
SeatPost:  X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4: 170mm, S5/S6: 190mm

Accessories
SWAT:  SWAT internal downtube storage
Product details

Weight: 24.42kg (S4)
